Manual Motor Starters
The ABB MS132 series of manual motor starters are compact highly reliable devices used to manually switch on and off motors. The MS132 series protects the motors reliably, without the need for a fuse, from short-circuits, overload and phase failures.
Short-circuit protection
Overload protection
Trip class 10 A
Phase loss sensitivity
ON/OFF switching functionality
Disconnecting feature
Specifications
| Attribute | Value |
|---|---|
| Power Rating | 4 kW |
| Motor Starter Type | DOL |
| Voltage Rating | 690 V ac |
| IP Rating | IP20 |
| Phase | 1, 3 |
| Number of Poles | 3P |
| Motor Starter Functionality | Manual |
| Overall Length | 90mm |
| Enclosure | Yes |
| Overall Width | 45mm |
| Overall Depth | 81.25mm |
| Series | MS132 |
